Growatt SYN 200-XH-US 200A Backup Transfer Box
Growatt SYN 200-XH-US 200A Backup Transfer Box
The Growatt SYN 200-XH-US is a whole-home backup transfer solution designed to integrate compatible Growatt hybrid inverter and battery systems with residential electrical service.
Built around a 200A grid-side breaker and 120/240V split-phase architecture, the SYN box provides automatic grid isolation and backup transfer for properly designed energy-storage systems.
Key Specifications
- Grid-side breaker: 200A
- System voltage: 120/240V split phase
- Automatic transfer time: less than 500 ms
- Communication: RS485
- Enclosure rating: IP65 / NEMA 4X
- Installation: wall mounted
- Dimensions: approximately 17.52 × 21.65 × 6.30 in
- Weight: approximately 58.9 lb
- Cooling: natural convection
- Operating noise: under 35 dB
Whole-Home Backup Integration
The SYN 200-XH-US is designed to manage the transition between utility power and a compatible Growatt backup-energy system. During an outage, the transfer system isolates the home from the utility grid and allows supported inverter and battery equipment to supply backed-up loads.
Designed for Hybrid Energy Systems
This transfer box is intended for use as part of a properly configured Growatt hybrid solar and battery installation. It provides the switching, protection, and communication functions required to coordinate utility power with supported backup equipment.
Outdoor-Ready Enclosure
The IP65 / NEMA 4X enclosure provides protection suitable for demanding residential installation environments while maintaining a compact wall-mounted footprint.
Safety & Compliance
- UL 1741
- UL 869A
- Applicable CSA compliance
- Manual bypass capability
- Integrated system communications
Professional Installation Required
This is service-level electrical equipment intended for professionally designed and installed systems. Inverter compatibility, battery configuration, service entrance requirements, permitting, disconnects, grounding, and local electrical code requirements must be verified for each installation.
Elevation UpScales can assist with equipment selection and system planning for larger backup-power and energy-storage projects.
